MEMS 16X16 MATRIX WEITCH
MEMS 16X16 is an integrated switch module based on coreray's MEMS 1x16 Optical Switch components,Thirty-two
MEMS 1x16 switches,sixteen for inputs and the other sixteen for outputs,are interconnected to form a fuIIy non-bIocking,two stage,optical cross-connect.Under this matrix switch platform,different MEMS 1xN switches can be
used to form customized MXN Switch Matrices.
.Compact form-factor
.Low insertion loss with minimal crosstalk
.Fast switching time
.Low power consumption
.MEMS durability and reliability
.Available in other customized configurations
APPLICATIONS
The MEMS 16x16 Mstrix is used in an optical network to dynamically configure the system.Mounting to any network card is easily achieved with its small form factor and 1"thickness.for Test and Measurement applica-tions,the matrlx switch is a simplifled alternative solution for fiber manage-ment and allows users to share resources.
OPTICAL SPECIFICATIONS
PARMETER RATING
lnsertion Loss3 Slngle-Bend 1.8dB max
Dual-Band 2.0 dB max
Crosstalk -70 dB max
Back Reflection -45 dB max
Switching Time 40 ms max
TDL 0.4 dB max
WDL 0.3 dB max
PDL 0.2 dB max
Repeatability 0.04 dB max
Durability cycles minOptical Power 500 mW max
Operating Temp -5 to 70℃
Storage Temp -40 to 85℃
Fiber Type 9/125 single mode
1,Speclflcations are wlthout conne ctors.
2,lL is measured at CWL,23℃.
3,WDL is measured in a +/- 20nm range at 23℃.
4,Repeata bility is defined after 100 cycles.
ELECTRICAL SPECIFICATIONS
PARAMETER RATING
Latching Type Non-latching
Control Type 13C or Rs232
Vcc Voltage 12 VDC
Power Consumption 700 mW max
Connector Type Molex 87833-1620
